Trunnion Mounted Ball Valve with Scotch Yoke Type Pneumatic Actuator

GMK’s trunnion-mounted ball valve with scotch yoke type pneumatic actuator has been designed to have superior sealing qualities and to be resistant to high pressures. A “trunnion” anchoring can be found at both the top and bottom of a trunnion-mounted ball with scotch yoke-type pneumatic actuator designs. No matter the pressure, this design ensures that a positive seal is maintained on both the downstream and the upstream seats. Ball valves with a trunnion design are capable of supporting activities with larger bores and higher pressures as a result. The following materials were used during the construction process: CF8, CF8M, CF3, CF3M, 4A, 5A, Alloy 20, UB6 904l, CK20, B148, and others. This valve comes in sizes ranging from DN50 up to DN1000.

Size Range:DN50-DN1000

Rating:150LB, 300LB ,600LB, 900LB, 1500LB

Operation:Hand lever, Wrench, Gear, Penumatic Actuator, Electric Actuator

Material:A105, F11, F22, LF2, F304, F316, F316L, F51, F53, F321, ect

Description
Technical
Standard
Q&A

DESCRIPTION

The GMK Trunnion Mounted Ball Valve with Scotch Yoke Type Pneumatic Actuator is a stopper device with a complete port design. There is a construction that is fire-resistant and safe. This valve is built to last and comes with an ISO 5211 mounting pad. In accordance with API 598 and API6D, it has been subjected to inspection and testing.

Benefits

The flanged design of the trunnion-mounted ball valve with scotch yoke type pneumatic actuator makes it very simple to attach the valve to the pipeline.
They provide the benefit of dependable performance in addition to the advantages of a small envelope and an affordable solution.
Trunnion-mounted ball valves can be modified to perform a wide variety of operations because of their adaptability.
They can be scaled up or down according to your demands to precisely meet the requirements of your pipeline.

Feature:

Full port design
Trunnion mounted ball type
Blow-out proof stem
Anti-Fire safe construction, Anti-statics device
Double Block and Bleed(D.B.B)
Stopper device
ISO 5211 mounting pad
Flanged or butt-welding ends
Free leakage of body sealed construction

Trunnion Mounted Ball Valve with Scotch Yoke Type Pneumatic Actuator

Application

Can be Single-acting, or double-acting.
Can be with the emergency handwheel.
Can be with ASCO solenoid Valve, SIMENS Positioner, ABB positioner, YTC positioner, Fisher positioner, Mesto Positioner, SMC filter, APL limit switch etc

TECHNICAL SPECS

Size Range DN50-DN1000

Rating 150LB, 300LB ,600LB, 900LB, 1500LB

Operation Hand lever, Wrench, Gear, Penumatic Actuator, Electric Actuator

Ends Connection RF Flanges, RTJ Flange, Butt Weld, Hub end, Groove

Material CF8, CF8M, CF3, CF3M, 4A, 5A, Alloy 20, UB6 904l, CK20, B148 ect

Supply ability 10000 piece/pieces per month

Port Wenzhou/shanghai

Payment terms L/C, D/A, D/P, T/T

Standard

Ball Valve design according to API6D, BS5351, ASME B16.34
Face to face ASME B16.10, AP6D
End Flanges ASME B16.5/ASME B16.47
Butt-welded ends ASME B16.25
Fire Safety API607, API6A
Inspection and test API 598, API6D
